Factory direct supply Orthosis Lumbar Back Support Spinal hyperextension fixed support

Adjustable hip joint fixed brace

[Product composition]: The product consists of plastic, composite cloth, metal frame, webbing, etc.

[Product function]: With the special hip hinge as the main body, it can control the adduction and abduction of the hip joint, but can freely flex and extend, and can set the rotation

Scope, supporting, fixing and limiting the hip joint.

(1) Upward rotation function: adjust the rotation angle of the rotary gear shaft above the flexion adjustable disc of the hip joint, so that the axis of the flexion adjustable disc can be aligned with the hip joint

The center of rotation of is concentric.

(2) Adjustable flexion limit function: the adjustable flexion limit disc can adjust the flexion and extension angle of the hip joint, and fix and limit the position.

(3) Abduction function: can adjust the hip joint abduction angle and fixation

(4) Descending function: It can adjust the rotation angle and fixation of hip joint, lower limb and foot.

[Note]: Please purchase and use under the guidance of a doctor.

Adjust the appropriate tightness when matching the product. Too tight will affect blood circulation, and too loose will affect the fixed support effect of the product

Use with caution if the ingredients are allergic.

Measure the patient's waist circumference

Measure the position of the waist close to the upper edge of the condylar bone protrusion. According to the measured data, cut and wear the waist. When cutting, leave 1-2 cm more than the measured waist. Then adjust the belt loop to make the waist fit more closely. The belt cord can be cut to ensure that the waist can be tightened. At the same time, the loop can be fixed at the front. Grasp the loop from both sides of the body, tighten and cross it, and fix the two loops on the opposite side. When tightening, it should feel comfortable, but not too tight, Just ensure the fixation effect of waist.

Wear hip assembly

Ensure that the hinge is positioned at or slightly higher than the big rotor. When positioning, the waist protector can be slightly pulled down, or adjusted later. First, stick the waist assembly to the waist. After fixing the hinge in place, adjust the pull rope to make it pass through the hole, and re fix the pull rope. After anchoring the hinge to the waist, check the reference position to ensure the space required by the hip joint. The hinge position should be slightly higher than the big rotor. The hinge axis is synchronized with the motion axis of the hip joint,

Adjust the lower part of the hip joint brace

To fix him to the thigh, you need to adjust the abduction and adduction direction. Use the hexagonal screwdriver attached with the package to adjust the abduction and adduction angle according to the patient's hip angle. Then adjust the length of the support according to the leg length. The thigh pad should be attached to the center of the thigh side. Next, perform a motion evaluation to ensure that the hip joint hinge is still in a reasonable position when the patient moves. Ask the patient to raise the hip joint as far as possible to about 90 degrees. When done, lower the leg as far back as possible, and initially set the hinge dial to 0-90 degrees. If the patient's hip joint motion exceeds 90 degrees or feels that the joint capsule is affected in the motion evaluation, it can be adjusted to 0-70 degrees.
